Brand - QNAP
BrandPartCode - TS-H2490FU-7232P-64G
Category - NAS & Storage Servers
Design - Chassis type - Rack (2U)
Design - Cooling type - Active
Design - Fan diameter - 6 cm
Design - LED indicators - HDD, LAN, Status
Design - Number of fans - 4 fan(s)
Design - Product colour - Black, Grey
EAN - 4713213518397
Gross Weight Kg - 20
GTIN - 0885022020416
GTIN - 885022020416
GTIN - 4713213518397
Logistics data - Harmonized System (HS) code - 84714100
LongDesc - ZFS-based, 24-bay U.2 NVMe all-flash storage built for high-performance and low-latency virtualized workloads, data centers, and 8K streamsThe NVMe all-flash TS-h2490FU is designed for providing extreme performance with high cost-efficiency. Featuring 24 U.2 NVMe Gen 3 x4 SSD bays, the TS-h2490FU delivers up to 661K / 245K random read/write IOPS with ultra-low latency. The ZFS-based QuTS hero operating system supports inline data deduplication and compression for reducing I/O and SSD storage consumption, which significantly extends SSD lifespan with a higher price-performance ratio for all-flash storage arrays. Coupled with near-unlimited snapshots, real-time SnapSync, and petabyte-scale storage expansion capabilities, theBuild high-performance storage infrastructure for IOPS-demanding applicationsVirtualizationEliminates storage bottlenecks for unstructured data and I/O intensive workloads; ideal for server virtualization and virtual desktop infrastructure (VDI).Data CentersDelivers ultra-low latency and high IOPS performance, providing response times within microseconds for data centers that host significant business-critical systems and data.Media and Entertainment (M&E) productionSatisfies smooth 4K/8K media streaming and post-production, empowering multimedia workflows with faster data transfer, access, and backup for boosted efficiency.2nd Gen AMD EPYC™ processors and DDR4 ECC memoryThe TS-h2490FU is armed with 2nd Gen AMD EPYC™ 7002 series processors (Rome). Based on the “Zen 2” architecture with cutting-edge 7nm process technology, up to 128 PCIe lanes of I/O are provided for 32Gb/s dedicated bandwidth per SSD. With DDR4 ECC memory that detects and corrects single-bit memory errors for higher reliability, the TS-h2490FU provides 8-channel modules and 16 Long-DIMM slots to fulfill memory-intensive workloads. Demonstrating immense computing power and multi-tasking capabilities, the TS-h2490FU is the ideal choice for uncompromising performance demands in HPC, virtualization, and hybrid/multi-cloud applications.U.2 NVMe Gen 3 x4 All-Flash Storage ArrayThe 2U rackmount TS-h2490FU has 24 drive bays for U.2 NVMe Gen 3 x4 SSDs, with each individual SSD having 32Gb/s dedicated bandwidth for the utmost application response times. Coupled with powerful ZFS data deduction and SSD optimization technologies, the TS-h2490FU provides solid foundations for overcoming complexity and performance demands in today’s evolving data center workloads.Empower high-speed data transfer with four 25GbE portsThe TS-h2490FU provides breakthrough network connectivity with two pre-installed dual-port 25GbE SFP28 SmartNICs* (that use the Broadcom NetXtreme®-E Series BCM57414, Mellanox® ConnectX®-4 Lx, or the same level SmartNIC). With failover and Port Trunking for up to 100Gb/s bandwidth, the TS-h2490FU empowers your organization with the bandwidth to tackle the most demanding applications, including data centers, virtualization, massive file transfer, high-speed backup/restoration, and multimedia transmission.Leverage the M.2 PCIe NVMe SSD to U.2 AdapterInstall one or more QDA adapter in the TS-h2490FU to maximize PCIe bandwidth utilization in a cost-effective way by using M.2 PCIe NVMe SSD instead of the U.2 SSD for optimizing data-intensive applications. It can also boost IOPS performance when configuring SSD caching. Users can monitor drive health and manage SSD usage from the QTS Storage & Snapshots Manager. The M.2 SSD installed in the QDA adapter is hot swappable.Multiple PCIe Gen 4 slots for flexible expansionThe TS-h2490FU is equipped with five PCIe Gen 4 slots. With twice the I/O performance of PCIe Gen 3, the TS-h2490FU can take advantage of many PCIe cards to expand application potential.Robust hardware paralleled to boost all-flash NVMe performanceThe TS-h2490FU features high-level hardware with an expandable architecture to provide businesses with high performance and low latency access. With a removable motherboard drawer design, IT staff can easily maintain the TS-h2490FU without needing to remove it from the rack.ZFS-based QuTS hero operating system enhances NAS performance and data integrityQuTS hero combines the app-based QTS with the 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management, virtualization, to collaborative media workflows, QuTS hero streamlines your business-critical tasks.Data integrity is keyQuTS hero’s self-healing ensures data integrity and reliability. Write Once, Read Many (WORM) is also supported.Data reduction improves storage efficiency and performanceInline data deduplication, compression, and compaction reduce file size to conserve storage capacity and optimize performance.Multi-level cache technologyMain memory read cache (L1 ARC), SSD second-level read cache (L2 ARC), and ZFS Intent Log (ZIL) for synchronous transactions with power fail protection are simultaneously supported to boost performance and security.RAID Z enables robust data protectionMultiple RAID levels allow flexible capacity utilization. RAID Triple Parity and Triple Mirror deliver higher levels of data protection.QSAL (QNAP SSD Antiwear Leveling) enhances data protectionRAID-level SSD lifespan is automatically and regularly detected to prevent simultaneous SSD failure, improving your data protection and system reliability.App Center ecosystem extends NAS functionalityApps for backup/sync, virtual machines/containers, content management, productivity, and more features can be used to expand the application potential of the TS-h2490FU.Inline data deduplication, compression, and compaction improve SSD enduranceQuTS hero supports advanced block-based data reduction technologies (including inline data deduplication, compression, and compaction) to reduce file sizes, conserve storage capacity, and optimize performance. For example, if 20 virtual machines on a NAS are replicated using the same template, then storage space requirements for all 20 virtual machines can be reduced by up to 95%. Whether acting as primary or backup storage, the TS-h2490FU optimizes storage utilization to provide a reliable storage cornerstone in the Big Data era. All-flash solutions thus achieve higher cost efficiency while improving both random write performance and SSD lifespan.More SSD performance and lifespan optimization technologiesWrite CoalescingTransforms all random writes to sequential writes along with reduced I/O, effectively increasing write performance in all-flash environments.Pool Over-provisioningDedicated space can be flexibly reserved in an SSD storage pool to allow new data to be written into a complete block even if the pool is almost full, thus improving the performance of fragmented pools.TRIMAllows QuTS hero to inform SSDs to delete unneeded data blocks and process the deletion tasks during system idle times, meaning it does not have to wait for when new data is written to the block.Real-time SnapSync ensures minimal RPO with real-time disaster recoveryReal-time SnapSync ensures that both the primary and secondary NAS maintain identical data. When data is written to the source, it is immediately written to the destination. If the primary NAS goes offline, IT staff can simply adjust the privilege settings of the secondary NAS to ensure continuous operations. SnapSync provides the strongest support for nonstop business operations and helps users to reduce the risk of data loss.Snapshots multiply backup protectionAttain peace of mind with near-limitless, instant snapshots. Copy-on-write technology makes snapshot creation almost instantaneous without affecting ongoing data writing. Snapshot Replica replicates snapshot files to the backup NAS, simplifying data protection with version control.HBS simplifies 3-2-1 backup plansHBS centralizes backup, restoration, and synchronization for easily transferring data in the TS-h2490FU to another QNAP NAS, remote server, or cloud storage space. HBS supports QuDedup technology that eliminates redundant data at the source and makes multi-version backup faster.All-in-one virtual machine and container hosting solutionYou can count on Virtualization Station and Container Station for comprehensive virtualization support. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.Virtualization StationRun multiple Windows®, Linux®, UNIX®, and Android™ virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without the need for additional physical servers.Container StationExperience LXC and Docker® lightweight virtualization technologies, download apps from the built-in Docker Hub Registry®, import and export containers, and create abundant microservices.Single Root I/O Virtualization (SR-IOV)By installing an SR-IOV compatible PCIe SmartNIC in the TS-h2490FU, you can allocate bandwidth resources from a physical network card directly to VMs. With traffic bypassing the Hypervisor vSwitch, it helps enhance I/O throughout and network efficiency, ensuring reliable VM applications and reduced CPU overheads.License-free VMware® and Hyper-V backup applianceWith Hyper Data Protector, the TS-h2490FU becomes an agentless backup tool for unlimited VMware® vSphere and Microsoft® Hyper-V VM backup. Hyper Data Protector features incremental backup, global deduplication, backup scheduling and recovery compression. Hyper Data Protector also simultaneously backs up multiple VMs, providing you with a cost-effective and reliable disaster recovery plan, ensuring 24/7 operation of your services.Move business data to the cloud and enjoy low latency access to cloud-based dataThe TS-h2490FU perfectly integrates NAS with mainstream cloud services. By deploying cloud storage gateways and enabling local caching, organizations can seamlessly use the cloud for storage, backup, and data recovery with low-latency access. This greatly helps in realizing cost-effective, flexible and secure hybrid cloud applications.HybridMount file-based cloud gatewayFlexibly expand storage capacity by connecting to cloud storage. You can leverage QuTS hero apps to manage and edit your cloud files or multimedia files. HybridMount is ideal for file server online collaboration and file-level data analysis.VJBOD Cloud block-based cloud gatewayVJBOD Cloud supports streamlined NAS backup to object cloud storage. The block-based data transmission uploads random data and large files to the cloud in blocks, and only transmits block-based volume or LUN changes (such as addition, modification, or deletion). This is ideal for enterprise-level applications with large file transfer requirements, such as databases, VM volumes, and videos.High-performance, reliable storage solution for virtualization- Supports block-based iSCSI LUN as a high-performance, reliable, and affordable storage solution for VMware®, Microsoft® Hyper-V®, and Windows Server® 2019 virtualization environments.- Supports VMware VAAI and Microsoft ODX to increase performance by offloading server loading for ESXi server and Hyper-V respectively, and supports QNAP vSphere Client plug-in with enhanced operational efficiency and management in virtualization applications.Build an affordable Fibre Channel SAN environmentCommon Fibre Channel Storage Area Networks (SAN) devices are often costly. By installing QNAP dual-port 16Gb/32Gb Fibre Channel expansion cards in the TS-h2490FU, you have more budget-friendly options to add a NAS to a SAN environment. You can set a Fibre Channel Target using the iSCSI & Fibre Channel app. Moreover, the LUN Masking and Port Binding features provide an additional layer of data security.More productivity applicationsBoxafeSafeguard enterprise cloud data by backing up/syncing files, emails, calendars and contacts from Google™ Workspace and Microsoft® Office 365® to the TS-h2490FU.Security CounselorA security portal for checking weaknesses and receiving recommendations for enhancing NAS security. It also integrates anti-virus and anti-malware scanning software.QsirchQNAP’s powerful, Google-like search tool helps you quickly find images, music, videos, documents, and emails by keywords, color, and more search conditions. It also supports Qfiling to perform one-time or automatic archival tasks based on your search criteria.Build a high-density petabyte-scale data center with Seagate® Exos™ E series JBODQNAP and Seagate® join hands to assist you in overcoming the challenges of extreme data growth! The TS-h2490FU supports connecting a Seagate Exos E series JBOD, offering a competitive storage solution with unprecedented capacity, industry-leading storage density, and high reliability while also minimizing TCO by saving rack space. You can flexibly install one or more QDA-UMP adapters with IronWolf 525 M.2 NVMe SSDs in the TS-h2490FU to maximize PCIe bandwidth utilization in a cost-effective way by using M.2 SSD instead of U.2 SSD for optimizing data-intensive applications.
LongProductName - 24 x 2.5", AMD EPYC 7232P, 64 GB RDIMM DDR4 ECC, 5GB Flash, LAN, 2 x 1100W, 100-240V, 88.3 × 480.97 × 510.23 mm, 15.2 kg
LongSummaryDescription - QNAP TS-h2490FU. Type: NAS. Chassis type: Rack (2U). Device class: Large Enterprise Business. Processor family: EPYC, Processor model: 7232P, Processor frequency: 3.1 GHz. Internal memory: 64 GB, Internal memory type: DDR4. Operating system installed: QuTS hero
Manufacturer Code - TS-H2490FU-7232P-64G
Manufacturer Name - QNAP
Memory - ECC - Yes
Memory - Flash memory - 5000 MB
Memory - Internal memory - 64 GB
Memory - Internal memory type - DDR4
Memory - Maximum RAM supported - 4 TB
Memory - Memory form factor - RDIMM
Memory - Memory slots - 16
Network - DHCP client - Yes
Network - DHCP server - Yes
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000,2500,25000 Mbit/s
Network - iSCSI support - Yes
Network - Jumbo frames support - Yes
Network - Link aggregation - Yes
Network - Load balancing system - Yes
Network - Supported network protocols - TCP/IP, IPv4, IPv6
Network - Wake-on-LAN ready - Yes
Network - WLAN adapter supported - Yes
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Fibre Channel - Yes
Packaging content - Cables included - AC, LAN (RJ-45)
Packaging content - Number of screws - 96
Packaging content - Power cables quantity - 2
Packaging content - Quick installation guide - Yes
Performance - Access Control List (ACL) - Yes
Performance - Backup features - Cloud, iSCSI LUN
Performance - Backup function - Yes
Performance - Browser supported - Mozilla Firefox, Microsoft Internet Explorer, Apple Safari, Google Chrome
Performance - Built-in FTP server - Yes
Performance - Buzzer - Yes
Performance - Device class - Large Enterprise Business
Performance - Hot spare - Yes
Performance - Multilingual support - Yes
Performance - Noise level - 53.5 dB
Performance - On/off switch - Yes
Performance - Reset button - Yes
Performance - S.M.A.R.T. support - Yes
Performance - Security algorithms - 256-bit AES, HTTPS, SSH, SSL/TLS
Performance - Snapshot - Yes
Performance - System log - Yes
Performance - Type - NAS
Performance - Universal Plug and Play (UPnP) - Yes
Performance - Web-based management - Yes
Ports & interfaces - Concurrent connections - 10000
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - Fiber optic connector - SFP28
Ports & interfaces - Fiber ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Ports & interfaces - USB port - Yes
Power - AC input voltage - 100 - 240 V
Power - Fan voltage - 12 V
Power - Number of power supply units - 2
Power - Power consumption (typical) - 277.64 W
Power - Power supply location - Built-in
Power - Power supply unit (PSU) capacity - 1100 W
Processor - L3 cache - 32 MB
Processor - Processor boost frequency - 3.2 GHz
Processor - Processor cores - 8
Processor - Processor family - EPYC
Processor - Processor frequency - 3.1 GHz
Processor - Processor manufacturer - AMD
Processor - Processor model - 7232P
Processor - Processor threads - 16
ProductName - TS-h2490FU
Short description - QNAP NAS TS-h2490FU-7232P-64G (24 Bay) 2U +++
ShortSummaryDescription - QNAP TS-h2490FU, NAS, Rack (2U), EPYC, 7232P, 64 GB, DDR4
Software - Linux operating systems supported - CentOS 7.0, SuSE Linux 12.0, SuSE Linux 12.3, SuSE Linux 15, Ubuntu 14.04, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, Ubuntu 18.04 LTS, Ubuntu 20.04 LTS
Software - Mac operating systems supported - Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Software - Operating system installed - QuTS hero
Software - Operating system version - h5.0.0
Software - Other operating systems supported - IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11
Software - Server operating systems supported - Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Software - Windows operating systems supported - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Storage - Bad block scan - Yes
Storage - Hot-swap drive bays - Yes
Storage - Installed storage drive type - No
Storage - Number of storage drives supported - 24
Storage - Online RAID expansion - Yes
Storage - Online RAID migration - Yes
Storage - RAID levels - 0, 1, 5, 6, 10, 50, 60
Storage - RAID rebuild - Yes
Storage - RAID support - Yes
Storage - Storage drives installed - No
Storage - Storage drive sizes supported - 2.5"
Storage - Supported file systems - FAT32, HFS+, NTFS, ZFS, ext3, ext4
Storage - Supported storage drive interfaces - U.2
Storage - Supported storage drive types - SSD
Title - QNAP TS-h2490FU NAS Rack (2U) EPYC 7232P 64 GB DDR4 QuTS hero Black, Grey
URL - https://www.qnap.com/en/product/ts-h2490fu
WarrantyInfo - 5 Years
Weight & dimensions - Depth - 510.2 mm
Weight & dimensions - Height - 88.3 mm
Weight & dimensions - Package weight - 21.9 kg
Weight & dimensions - Weight - 15.2 kg
Weight & dimensions - Width - 481 mm
