Chieftec Visio, Panoramic Tempered Glass, Black

Accessories included - Zestaw śrub, instrukcja obsługi Dół: 2 x wentylator PWM 140mm, zainstalowane fabrycznie Tył: wentylator PWM 140mm, zainstalowany fabrycznie
Brand - Chieftec
BrandPartCode - GM-30B-M-OP
Category - Computer Cases
Category - Root/Electronics/PC parts/Computer casings
Chassis type - Midi Tower
Color - Black
Computer case backlight - Yes
Cooling - Bottom fans installed - 2x 140 mm
Cooling - Liquid cooling capability - Yes
Cooling - Rear fans installed - 1x 140 mm
Cooling - Top radiator sizes supported - 240,280,360 mm
Description - Obudowa Visio AIR GM-30 B-M-OP 3xwentylator Obudowa CHIEFTEC Visio Air Performance jest wyposażona w dwukomorowy design, który obsługuje najnowsze płyty główne z tylnymi złączami i optymalizuje zarządzanie kablami dla czystego wnętrza (kompatybilna z ASUS BTF i MSI Project Zero). Visio Air posiada hartowane szkło po bokach oraz przód łączący szczotkowane aluminium z panelami mesh, oraz jest wyposażona w dwa fabrycznie zamontowane wentylatory PWM 140 mm na dole i jeden wentylator PWM 140 mm z tyłu. Ten projekt zwiększa stabilność i przepływ powietrza, skutecznie redukując nagrzewanie się wnętrza obudowy i utrzymując niski poziom hałasu.
Przemyślany układ wewnętrzny umożliwia montaż radiatorów o wymiarach 360 mm na górze i na dole, radiatorów 240 mm po stronie płyty głównej oraz chłodzeń CPU o wysokości do 175 mm. Dzięki przestronnej i dobrze wentylowanej konguracji, można łatwo pomieścić wysokiej klasy karty graficzne o długości do 410 mm.
CHIEFTEC Visio Air jest wystarczająco wszechstronna do użytku zarówno w biurze, jak i w domu, co czyni ją praktycznym wyborem do różnych zastosowań. Dwukomorowy design Kombinacja z przodu z aluminium szczotkowanego i siatkowej blachy Boczna ścianka z hartowanego szkła Kompatybilność z płytami głównymi z tylnymi złączami 3x wentylatory PWM 140mm zainstalowane fabrycznie
Design - Anti-dust filter - Yes
Design - Form factor - Cube
Design - Full-Height expansion slots - 6
Design - Illumination - No
Design - Maximum CPU cooler height - 17.5 cm
Design - Maximum graphics card length - 41 cm
Design - Maximum PSU length - 20 cm
Design - Number of 2.5" bays - 2
Design - Number of 3.5" bays - 2
Design - Number of expansion slots - 6
Design - Number of internal 3.5" bays - 2
Design - Number of storage drives supported - 4
Design - Product colour - Black
Design - Side window - Yes
Design - Suitable for - Gaming
Design - Supported motherboard form factors - ATX, micro ATX
Design - Tempered glass panel(s) - Yes
Design - Type - PC
Designation - CE+WEEE
dimension depth - 470 mm
dimension height - 530 mm
Dimensions - 390 x 295 x 430 mm
dimension weight - 9000 g
dimension width - 380 mm
Drive bays 2.5'' extern. - 0
Drive bays 2.5'' intern. - 2
Drive bays 3.5'' extern. - 0
Drive bays 3.5'' intern. - 2
Drive bays 5.25'' extern. - 0
Drive bays 5.25'' intern. - 0
ean - 753263078704
Eans - 753263078704
Fans installed - 1 x 140 mm (back)
Fans installed - 2 x 140 mm (bottom)
Form-factor - ATX
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x headphones
Front panel connectors - 1 x UB1 x USB 3.2 Gen 2 Type-CavS 3.2 Gen 2 Type-C
Front panel connectors - 2 x USB 3.0
guarantee - 24
guarantee_type - normal
LongDesc - The CHIEFTEC Visio Air performance chassis features a dual-chamber layout to accommodate the latest back-connect motherboards, streamlining cable management for a cleaner interior view (ASUS BTF and MSI Project Zero compatible). The Visio Air comes with tempered glass on the side, a front combining brushed aluminum and mesh panel, along with two pre-installed 140mm PWM fans on the bottom and one 140mm PWM fan on the rear. This design enhances stability and airflow, effectively reducing heat accumulation inside the chassis while keeping noise levels low.The rened internal layout supports the mounting of 360mm radiators on the top and bottom, 240mm radiators on the motherboard side, and CPU tower coolers up to 175mm in height. High-end GPUs up to 410mm can be easily accommodated, thanks to its spacious and well-ventilated conguration.The CHIEFTEC Visio Air is versatile enough for both work and home environments, making it a practical choice for various settings.
LongProductName - CHIEFTEC | Visio Air | GM-30B-M-OP | Dual-Chamber ATX Gaming Case, Mesh Front, Tempered Glass, Black
LongSummaryDescription - Chieftec mATX Gehäuse GM-30B-M-OP, black. Form factor: Cube, Type: PC, Product colour: Black. Rear fans installed: 1x 140 mm, Bottom fans installed: 2x 140 mm, Top radiator sizes supported: 240,280,360 mm. Supported HDD sizes: 2.5,3.5". Width: 295 mm, Depth: 430 mm, Height: 390 mm
Maximum CPU cooling height - 175 mm
Maximum length of the graphics card - 410 mm
Maximum length of the power supply - 200 mm
Maximum number of fans - 9
Name - Chieftec Visio Air GM-30B-M-OP
name - PC case Visio AIR GM-30 B-M-OP 3xfan
No. of drive bays - 4
Number of fans installed - 3
Number of slots for expansion cards - 6
Ooptional water cooling - 1 x 240 mm (bottom)
Ooptional water cooling - 1 x 240 mm (góra)
Ooptional water cooling - 1 x 240 mm (side)
Ooptional water cooling - 1 x 280 mm (bottom)
Ooptional water cooling - 1 x 280 mm (góra)
Ooptional water cooling - 1 x 360 mm (bottom)
Ooptional water cooling - 1 x 360 mm (top)
Optional fans - 1 x 120 mm or 1 x 140 mm (rear)
Optional fans - 2 x 120 mm (side)
Optional fans - 3 x 120 mm lub 2 x 140 mm (bottom)
Optional fans - 3 x 120 mm or 2 x 140 mm (top)
Other features -
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
Ports & interfaces - USB Type-C ports quantity - 1
Power supply - Failure
Power supply - Power supply included - No
producer - Chieftec
Producer - Chieftec
ProducerCode - GM-30B-M-OP
ProductName - mATX Gehäuse GM-30B-M-OP, black
ShortDescription - Middle Tower | czarna | 1x USB3.2 Gen2 Typ C, 2 x USB3.0 | 430mm x 295mm x 390mm |
ShortSummaryDescription - Chieftec mATX Gehäuse GM-30B-M-OP, black, Cube, PC, Black, ATX, micro ATX, Gaming, 17.5 cm
Side panel - Tempered Glass
Storage - HDD/SSD combo cage - Yes
Storage - Supported HDD sizes - 2.5,3.5"
Title - Chieftec mATX Gehäuse GM-30B-M-OP, black Cube
URL - https://www.chieftec.eu/products-detail/588/GM-30B-M-OP
vendpn - GM-30B-M-OP
Video -
WarrantyInfo - 24 Months
Weight - 6.8 kg
Weight & dimensions - Depth - 430 mm
Weight & dimensions - Height - 390 mm
Weight & dimensions - Weight - 6.8 kg
Weight & dimensions - Width - 295 mm
