Asus TUF Gaming GT502 PLUS, Tempered Glass, White

2.5"/3.5" Internal Drive Bays - 4
Accessories included -
ATX Mainboard Form Factor - Yes
Brand - ASUS
BrandPartCode - 90DC0093-B19000
Case product features - Transparent panel
Case Type - MidiTower
category - Cases & Modding|PC Cases
Category - Computer Cases
Category - Root/Electronics/PC parts/Computer casings
Category Code - CAS
Chassis type - Midi Tower
code - 90DC0093-B19000
Color - White
Colour - White
Computer case backlight - No
Cooling - Number of rear fans supported (max) - 1
Cooling - Number of top fans supported (max) - 3
Cooling - Rear fans diameters supported - 120 mm
Cooling - Rear radiator sizes supported - 120 mm
Cooling - Top fans diameters supported - 120
Cooling - Top fans diameters supported - 120,140 mm
Cooling - Top fans diameters supported - 140 mm
Cooling - Top radiator sizes supported - 120
Cooling - Top radiator sizes supported - 120,140,240,280,360 mm
Cooling - Top radiator sizes supported - 140
Cooling - Top radiator sizes supported - 240
Cooling - Top radiator sizes supported - 280
Cooling - Top radiator sizes supported - 360 mm
Description - Obudowa TUF Gaming GT502+
Obudowa dwukomorowa
TUF Gaming GT502 PLUS umożliwia stworzenie niezależnych stref chłodzenia dla CPU i GPU.
Panoramiczny widok
Panele z hartowanego szkła są gustownie przyciemnione i zapewniają wgląd do wewnątrz do prezentacji systemu.
Superszybki port USB Type-C na panelu przednim
Na panelu przednim znajduje się port USB 3.2 Gen 2 Type-C, który zapewnia szybkości transferów do 10 Gb/s.
Panele boczne montowane bez użycia narzędzi
Panele boczne można łatwo zdjąć, naciskając przycisk ukryty z tyłu obudowy.
Description - TUF Gaming GT502 - Dual Chamber Chassis. TUF Gaming GT502 configures independent cooling zones for the CPU and GPU - Panoramic View?. Tempered glass panels provide a tactfully tinted view for showcasing your build? - Front Panel High-Speed USB Type-C?. The front panel features a USB 3.2 Gen 2 Type-C port ripe for transfer speeds up to 10 Gbps? - Tool-Free Side Panels. The side panels can be removed simply by pressing a button hidden on the rear of the chassis
Design - Anti-dust filter - Yes
Design - Form factor - Midi Tower
Design - Maximum CPU cooler height - 16.3 cm
Design - Maximum graphics card length - 40 cm
Design - Maximum PSU length - 20 cm
Design - Number of 2.5" bays - 4
Design - Number of 3.5" bays - 4
Design - Number of expansion slots - 8
Design - Product colour - White
Design - RGB control button - Yes
Design - Supported motherboard form factors - ATX
Design - Supported motherboard form factors - ATX, micro ATX, Mini-ITX
Design - Supported motherboard form factors - micro ATX
Design - Supported motherboard form factors - Mini-ITX
Design - Tempered glass panel(s) - Yes
Design - Type - PC
dimensionalWeight - 22840
dimension depth - 560 mm
dimension height - 520 mm
Dimensions - 285 x 450 x 446 mm
dimension weight - 12000 g
dimension width - 400 mm
Drive bays 2.5'' extern. - 0
Drive bays 2.5'' intern. - 4
Drive bays 3.5'' extern. - 0
Drive bays 3.5'' intern. - 4
Drive bays 5.25'' extern. - 0
Drive bays 5.25'' intern. - 0
ean - 4711387204689
Eans - 4711387204689
Fans installed - 1 x 120 mm ARGB (back)
Fans installed - 3 x 120 mm ARGB (top)
Form-factor - ATX
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x headphones
Front panel connectors - 1 x UBS 3.2 Gen 2x2 Type-C
Front panel connectors - 2 x USB 3.2 Gen1
Front panel connectors - Light control
Full Description Line - TUF Gaming GT502|MidiTower|PSU Not included|Dimensions 285 x 450 x 446 mm
GTIN - 4711387204689
guarantee - 24
guarantee_type - normal
Headphones jack Input/Output connectors - 1
LongDesc - It’s Wonderfully Split!Dual Chamber ChassisTUF Gaming GT502 PLUS configures independent cooling zones for the CPU and GPUPanoramic View​Tempered glass panels provide a tactfully tinted view for showcasing your build​Front Panel High-Speed USB Type-C​The front panel features a USB 3.2 Gen 2 Type-C port ripe for transfer speeds up to 10 Gbps​Tool-Free Side PanelsThe side panels can be removed simply by pressing a button hidden on the rear of the chassisIT'S WONDERFULLY SPLIT!​​Flexible, scalable, and divided up in all the right ways: the TUF Gaming GT502 PLUS puts your prized hardware up front and holds your six with a stack of cooling options, bundled system fans, and an ARGB lighting hub to express ultimate performance your way. Load up, lock in, and watch it all thrive. DUAL-CHAMBER CHASSISCLIMATE CONTROLGT502 PLUS internals are divided into two chambers, allowing you to build clean and configure independent cooling zones for the CPU and GPU. Freely expand your rig and give system components the ideal environment to dish out frames and slice through workloads.DISCRETE ARGB HUBHIDDEN IN PLAIN SIGHTAn integrated ARGB hub that supports up to six Aura Sync devices is neatly tucked away under a sleek cover, keeping cable connections in the shade while your system components bask in a customizable glow.TOOL-FREE SIDE PANELSFINGER-FRIENDLY RESTRICTIONSThe TUF Gaming GT502 PLUS continues its builder optimizations with side panels that can be removed simply by pressing a button hidden on the rear of the chassis.PANORAMIC VIEWSINGLE-STATE PEEKABOOTempered glass panels at the front and side provide a tactfully tinted view of the main chamber, showcasing your build to own the room.FRONT PANEL HIGH-SPEED USB TYPE-CWITHIN ARM’S REACHIn addition to two USB-A ports, the TUF Gaming GT502 PLUS front panel features a USB 3.2 Gen 2 Type-C port ripe for transfer speeds up to 10 Gbps.TUF GAMING-STYLE WOVEN STRAPSWEAVE HO!Two durable and detachable straps that can support up to 30 kg (66 lbs) make it much easier to move the chassis around even when it’s packed with hardware.FULLY MODULAR DESIGNDOWN TO THE SKELETONWhether you prefer a modest build or a fully-loaded battle station, the GT502 PLUS is ready. Most of its panels and mounts are removable to ease hardware installation – take it apart to your heart’s content then build it up in your ideal image.
LongProductName - TUF Gaming GT502 PLUS, Tempered glass panel, USB 3.2 Gen 2 Type-C, 285 x 450 x 446 mm
LongSummaryDescription - ASUS TUF Gaming GT502 PLUS. Form factor: Midi Tower, Type: PC, Product colour: White. Rear fans diameters supported: 120 mm, Top fans diameters supported: 120,140 mm, Rear radiator sizes supported: 120 mm. Supported HDD sizes: 2.5,3.5". Width: 285 mm, Depth: 446 mm, Height: 450 mm. Package width: 380 mm, Package depth: 557 mm, Package height: 525 mm
Maximum CPU cooling height - 163 mm
Maximum length of the graphics card - 400 mm
Maximum length of the power supply - 200 mm
Maximum number of fans - 13
MicroATX Mainboard Form Factor - Yes
MiniITX Mainboard Form Factor - Yes
Model name - TUF Gaming GT502
name - ASUS TUF Gaming GT502 Plus TG Midi-Tower - weiß
Name - ASUS TUF Gaming GT502 Plus TG White
name - PC case TUF Gaming GT502+ white
No. of drive bays - 4
Number of expansion slots - 8 + 3
Number of fans installed - 4
Number of slots for expansion cards - 11
Ooptional water cooling - 1 x 120 mm (back)
Ooptional water cooling - 1 x 120 mm (side)
Ooptional water cooling - 1 x 120 mm (top)
Ooptional water cooling - 1 x 140 mm (side)
Ooptional water cooling - 1 x 140 mm (top)
Ooptional water cooling - 1 x 240 mm (góra)
Ooptional water cooling - 1 x 240 mm (side)
Ooptional water cooling - 1 x 280 mm (góra)
Ooptional water cooling - 1 x 280 mm (side)
Ooptional water cooling - 1 x 360 mm (side)
Ooptional water cooling - 1 x 360 mm (top)
Optional fans - 1 x 120 mm (back)
Optional fans - 3 x 120 mm (bottom)
Optional fans - 3 x 120 mm (side)
Optional fans - 3 x 120 mm or 2 x 140 mm (side)
Optional fans - 3 x 120 mm or 2 x 140 mm (top)
Other features - Gniazda rozszerzeń: 8 + 3 (dodatkowy pionowy)
Packaging data - Package depth - 557 mm
Packaging data - Package height - 525 mm
Packaging data - Package weight - 13.2 kg
Packaging data - Package width - 380 mm
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
Power supply - Failure
producer - Asus
Producer - Asus
producerCode - 90DC0093-B19000
ProducerCode - 90DC0093-B19000
productName - ASUS TUF Gaming GT502 PLUS Midi Tower White
ProductName - TUF Gaming GT502 PLUS
productSize - Normal
PSU - Not included
Shipping Box Depth Shipping/Package Box Dimensions - 56 cm
Shipping Box Height Shipping/Package Box Dimensions - 52.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 14 kg
Shipping Box Width Shipping/Package Box Dimensions - 39 cm
ShortDescription - Middle Tower | biała | bez zasilacza | 2 x USB 3.2 | 285 mm x 450 mm x 446 mm |
ShortSummaryDescription - ASUS TUF Gaming GT502 PLUS, Midi Tower, PC, White, ATX, micro ATX, Mini-ITX, 16.3 cm, 40 cm
Side panel - Tempered Glass
sizeX - 565
sizeY - 525
sizeZ - 385
Storage - Supported HDD sizes - 2.5
Storage - Supported HDD sizes - 2.5,3.5"
Storage - Supported HDD sizes - 3.5"
Title - ASUS TUF Gaming GT502 PLUS Midi Tower White
Unit Box Height - 0.525
Unit Box Length - 0.56
Unit Box Width - 0.39
Unit Brutto Volume - 0.1147 cubm
Unit Gross Weight - 14 kg
Unit Net Weight - 11 kg
URL - https://www.asus.com/motherboards-components/cases/tuf-gaming/tuf-gaming-gt502-plus/
USB-C Input/Output connectors - 1
USB 3.2 Input/Output connectors - 2
Vendor Homepage - www.asus.com/motherboards-components/cases/tuf-gaming/tuf-gaming-gt502/
vendpn - 90DC0093-B19000
Warranty - 24 months
WarrantyInfo -
warrantyLength - 24
warrantyType - G
Weight - 11.9 kg
weight - 13700
Weight & dimensions - Depth - 446 mm
Weight & dimensions - Height - 450 mm
Weight & dimensions - Weight - 11 kg
Weight & dimensions - Width - 285 mm
