Accessories included - Quick guide
Brand - GIGABYTE
BrandPartCode - GV-N4060AERO OC-8GD
Card's length - > 280 mm
Category - Graphics Cards
category - PC Components|Graphics Cards|NVIDIA|GeForce RTX 4070
Category - Root/Electronics/PC parts/Graphic cards
Category 1 - Grafikkarten
Category 2 - NVidia PCI-Express Grafikkarten
Category Code - VGP
Category_1 - Graphics Cards
Category_2 - Graphics Cards PCIe - Nvidia
Chipset - GeForce RTX 4060 Ti
Chipset - NVIDIA GeForce RTX 4060
Chipset manufacturer - NVIDIA
code - GV-N4060AERO OC-8GD
Code - GV-N4060AERO OC-8GD
Cooling - Active
Cooling system - Dual Slot Fansink
CUDA Core - 3072
CUDA Cores - 3072
Description - GeForce RTX™ 4060 AERO OC 8G KEY FEATURE - Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing - 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering - 3rd Generation RT Cores: Up to 2X ray tracing performance - Powered by GeForce RTX™ 4060 - Integrated with 8GB GDDR6 128bit memory interface - WINDFORCE Cooling System - RGB Fusion - Dual BIOS - Protection metal back plate CORE CLOCK - TBD
Description - Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace Arc and full ray tracing 4th Gen Tensor Cores: Up to 4x faster performance with DLSS 3 compared to brute force rendering 3rd Gen RT Cores: Up to 2X ray tracing performance Powered by GeForce RTX 4060 Integrated with 8GB GDDR6 128-bit memory interface WINDFORCE cooling system RGB fusion Dual BIOS Protective metal backplate
Design - Cooling type - Active
Design - Form factor - Full-Height/Full-Length (FH/FL)
Design - Number of fans - 3 fan(s)
Design - Product colour - White
dimensionalWeight - 1080
dimension depth - 85 mm
dimension height - 190 mm
Dimensions - 281 x 114 x 38 mm
Dimensions - 281x114x38mm
dimension weight - 1013 g
dimension width - 365 mm
DisplayPort Input/Output connectors - 2
EAN - 4719331313661
ean - 4719331313661
Eans - 4719331313661
EAN_code - 4719331313661
Full Description Line - NVIDIA GeForce RTX 4060|Graphics memory size 8 GB|GDDR6|128 bit|PCIE 4.0 16x|Memory CLK 17 Gbps|7680x4320|Cooling Dual Slot Fansink|2xHDMI|2xDisplayPort
Graphics card connector - PCI-E ver. 4.0
Graphics connector - PCIE 4.0 16x
Graphics memory size - 8 GB
Graphics memory type - GDDR6
Gross Weight Kg - 1,69
GTIN - 0889523038550
GTIN - 889523038550
GTIN - 4719331313661
guarantee - 36
guarantee_type - normal
HDMI Input/Output connectors - 2
Link - https://www.gigabyte.com/Graphics-Card/GV-N4060AERO-OC-8GD#kf
LongDesc - WINDFORCE COOLING SYSTEMThe WINDFORCE cooling system features three 80mm unique blade fans, alternate spinning, composite copper heat pipes that directly touch the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.ALTERNATE SPINNINGReduce the turbulence of adjacent fans and increase airflow pressure.3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.UNIQUE BLADE FANThe airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.GRAPHENE NANO LUBRICANTGraphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieterOPTIMIZED THERMAL MODULEThe pure copper heat pipe makes direct contact with the GPU to facilitate enhanced heat transfer to the heatsink, optimizing the cooling efficiency of the graphics card.RGB FUSIONWith 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.PROTECTION METAL BACK PLATEThe metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.DUAL BIOSThe factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.POWER INDICATORWhen experiencing any power supply abnormality, the indicator will alert gamers by flashing light.ULTRA COOLINGLower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.LOW POWER LOSSMetal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.LONGER LIFELower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespanFRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.Power Through The GameGIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.GIGABYTE CONTROL CENTERGIGABYTE CONTROL CENTER is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
LongProductName - NVIDIA GeForce RTX 4060, 2550MHz, 8GB GDDR6, 128 bit, PCI Express 4.0, 2 x HDMI (2.1a), 2 x DP (1.4a), CUDA, DirectX 12 Ultimate, OpenGL 4.6
LongSummaryDescription - GIGABYTE AERO GeForce RTX 4060 OC 8G. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 4060, Processor frequency: 2550 MHz. Discrete graphics card memory: 8 GB, Graphics card memory type: GDDR6, Memory bus: 128 bit. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 3 fan(s)
Manufacturer - GigaByte
Manufacturer - Gigabyte
Manufacturer Code - GV-N4060AERO OC-8GD
Manufacturer Name - Gigabyte
Manufacturer_code - GV-N4060AERO OC-8GD
Max resolution - 7680x4320
Memory - Discrete graphics card memory - 8 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bus - 128 bit
Memory > Discrete graphics adapter memory - 8 GB
Memory > Graphics adapter memory type - GDDR6
Memory > Memory clock speed - 21000 MHz
Memory bus - 128 bit
Memory bus - 128-bit
Memory CLK - 17 Gbps
Memory frequency - 17 Gbps
Memory type - DDR6
Model - GV-N4060AERO OC-8GD
MPN - GV-N4060AERO OC-8GD
Name - GIGABYTE GeForce RTX 4060 AERO OC, graphics card (white, DLSS 3, 2x DisplayPort, 2x HDMI 2.1)
name - GIGABYTE GeForce RTX 4060 Aero OC 8G, 8192 MB GDDR6
Name - Gigabyte GeForce RTX 4060 AERO OC 8GB DLSS 3
Name - Gigabyte | GV-N4060AERO OC-8GD 1.0 | NVIDIA | 8 GB | GeForce RTX 4060 | GDDR6 | HDMI ports quantity 2 | PCI-E 4.0 | Memory clock speed 21000 MHz
name - Graphics Card GeForce RTX 4060 AERO OC 8G GDDR6 128bit 2DP/2HDMI
Name - RTX 4060 8GB Gigabyte Aero OC GDDR6 3Fan
Other features -
Other information - Maximum digital resolution 7680x4320 Many views 4 ATX PCB form 450W power supply recommended Power connectors 8 pins * 1
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 330.00 mm
Package features > Gross depth master carton - 725 mm
Package features > Gross height (mm) - 90.00 mm
Package features > Gross height master carton - 310 mm
Package features > Gross width (mm) - 160.00 mm
Package features > Gross width master carton - 465 mm
Package features > Net weight master carton - 16 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 364 pc(s)
Package features > Paper/Pasteboard - 150.00 g
Package features > Plastic (No PET) - 50.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > Tare weight master carton - 1.777 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - No
Packaging content - Quick installation guide - Yes
Packaging data - Package type - Box
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - HDCP - Yes
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - HDMI version - 2.1a
Ports & interfaces - Interface type - PCI Express 4.0
Ports & interfaces > DisplayPorts quantity - 2
Ports & interfaces > HDMI ports quantity - 2
Ports & interfaces > Interface type - PCI-E 4.0
Power - Minimum system power supply - 450 W
Power - Supplementary power connectors - 1x 8-pin
Power connectors - 8 pin
Power consumption - 450 Watts
Processor - CUDA - Yes
Processor - CUDA cores - 3072
Processor - Graphics processor - GeForce RTX 4060
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor boost clock speed - 2550 MHz
Processor - Processor frequency - 2460 MHz
Processor - Processor frequency - 2550 MHz
Processor > Graphics processor - GeForce RTX 4060
Processor > Graphics processor family - NVIDIA
producer - Gigabyte
Producer - Gigabyte
producerCode - GV-N4060AERO OC-8GD
ProducerCode - GV-N4060AERO OC-8GD
Producer product name - GV-N4060AERO OC-8GD 1.0
ProductName - GeForce RTX 4060 AERO OC 8G
productName - Gigabyte GeForce RTX 4060 AERO OC 8G NVIDIA 8 GB GDDR6
productSize - Normal
Shipping Box Depth Shipping/Package Box Dimensions - 36.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 8.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.993 kg
Shipping Box Width Shipping/Package Box Dimensions - 18.5 cm
ShortDescription - Chipset NVIDIA RTX 4060 | 8GB |
Short description - GIGA VGA 8GB RTX4060 AERO OC 8G 2xDP/2xHDMI GeForce RTX 4060 AERO OC 8G
ShortSummaryDescription - GIGABYTE AERO GeForce RTX 4060 OC 8G, GeForce RTX 4060, 8 GB, GDDR6, 128 bit, 7680 x 4320 pixels, PCI Express 4.0
sizeX - 365
sizeY - 80
sizeZ - 185
Supported standards - DirectX 12 Ultimate
Supported standards - OpenGL 4.6
Technical details > Gross weight - 1.81 kg
Technical details > Net weight - 1.61 kg
Technical details > Producer - Gigabyte
Technical_details - The GIGABYTE GeForce RTX 4060 AERO OC is a high-end graphics card with the GeForce RTX 4060 GPU from NVIDIA. The powerful GeForce RTX 40 graphics card series is based on the NVIDIA Ada architecture and offers new levels of gaming realism, speed and performance efficiency, RTX IO and realistic VR experiences. Other features include Real-Time Ray Tracing, NVIDIA Ansel, with extensive tools for creating screenshots in games as well as NVIDIA G-SYNC, G-SYNC HDR, DirectX 12 Ultimate, NVIDIA DLSS 3.0, PCI Express Gen 4, NVIDIA FreeStyle, NVIDIA ShadowPlay , NVIDIA Highlights, NVENC Gen 8, AV1 Encoder, Vulkan RT API and OpenGL 4.6. The GPU installed on the GIGABYTE GeForce RTX 4060 AERO OC has 3072 CUDA cores. The 8 GB GDDR6 memory has a 128-bit memory controller. Item no.: 100001352 Graphics card type color white EAN 4719331313661 Manufacturer no. GV-N4060AERO OC-8GD Slot PCIe x16 version 4.0 occupied slots 2 GPU name NVIDIA GeForce RTX 4060 Required power supply power at least 450 W Memory capacity 8 GB (GDDR6) Connections 2x HDMI version 2.1, 2x Displayport version 1.4a Power supply Average consumption 115 W Cooling Cooling with fan Special features VR Ready Yes Operating systems Supports Windows 11, Windows 10 Feature RTX IO, NVIDIA DLSS 3.0, PCI Express Gen 4, NVIDIA GeForce Experience, NVIDIA Ansel, NVIDIA FreeStyle, NVIDIA ShadowPlay, NVIDIA Highlights, NVIDIA G-SYNC, Game Ready Driver, NVIDIA Studio Driver, NVIDIA GPU Boost, NVENC Gen 8, AV1 Encoder, Vulkan RT API More information Maximum digital resolution: 7680 x 4320 Dimensions Width: 114mm x Height: 38mm x Depth/Length: 281mm Weight 880 grams
Title - GIGABYTE AERO GeForce RTX 4060 OC 8G NVIDIA 8 GB GDDR6
Unit Box Height - 0.085
Unit Box Length - 0.365
Unit Box Width - 0.185
Unit Brutto Volume - 0.00574 cubm
Unit Gross Weight - 0.993 kg
Unit Net Weight - 0.7 kg
URL - https://www.gigabyte.com/Graphics-Card/GV-N4060AERO-OC-8GD#kf
Vendor Homepage - www.gigabyte.com/Graphics-Card/GV-N4060AERO-OC-8GD#kf
vendpn - GV-N4060AERO OC-8GD
Version - Box
Video ports - 2 x DisplayPort
Video ports - 2 x HDMI
VRAM memory size - 8 GB
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo -
warrantyLength - 24
warrantyType - G
Weight - 0.96
Weight - 1,00
weight - 990
Weight & dimensions - Depth - 38 mm
Weight & dimensions - Depth - 281 mm
Weight & dimensions - Height - 38 mm
Weight & dimensions - Height - 114 mm
Weight & dimensions - Width - 114 mm
GeForce embleem näitab, et see graafikakaart on piisavalt võimas, et ühilduda uusimate VR (Virtual Reality) seadmetega nagu Oculus Rift, HTC Vive (SteamVR) jne.
