Asus Radeon RX 9070, 16GB GDDR6, Prime OC

Brand - ASUS
BrandPartCode - 90YV0LI1-M0NA00
Card's length - > 280 mm
Category - Graphics Cards
Category Code - VGP
Chipset - AMD Radeon RX 9070
Cooling system - Triple slot Fansink
Description - ASUS Prime Radeon™ RX 9070 OC Edition 16GB GDDR6 Experience Primal performance with the Prime Radeon™ RX 9070 graphics card featuring a compact 2.5-slot design for expansive compatibility, enhanced by a phase-change GPU thermal pad and a triple-fan setup for supreme cooling.
Design - Bracket height - Full-Height (FH)
Design - Cooling technology - ASUS Axial-tech
Design - Cooling type - Active
Design - Form factor - Full-Height/Full-Length (FH/FL)
Design - Number of fans - 3 fan(s)
Design - Number of slots - 2.5
Design - Product colour - Black
dimensionalWeight - 1713
Dimensions - 312 x 130 x 50 mm
DisplayPort Input/Output connectors - 3
Full Description Line - AMD Radeon RX 9070|Graphics memory size 16 GB|GDDR6|256 bit|PCIE 5.0 16x|Memory CLK 20 Gbps|7680x4320|Cooling Triple slot Fansink|1xHDMI|3xDisplayPort
Graphic card features - Gaming/HDCP/Overclock Edition
Graphics connector - PCIE 5.0 16x
Graphics memory size - 16 GB
Graphics memory type - GDDR6
GTIN - 4711387829592
HDMI Input/Output connectors - 1
LongDesc - Primed for PowerExperience Primal performance with the Prime Radeon™ RX 9070 graphics card featuring a compact 2.5-slot design for expansive compatibility, enhanced by a phase-change GPU thermal pad and a triple-fan setup for supreme cooling.Cooling2.5-slot DesignThe Prime Radeon™ RX 9070 features a 2.5 slot design with a carefully arranged layout for the shroud, heatsink and heat pipes to let the three Axial-tech fans leverage chassis side-panel ventilation and deliver optimal thermal performance.Axial-tech UpgradesThree tried-and-true Axial-tech fans feature a smaller hub that facilitates longer blades and a barrier ring to increase downward air pressure for lower temperatures, less noise and higher performance.0dB TechnologyAll three fans come to a standstill when GPU temperatures are below 55°C, letting you play less demanding games or perform light tasks in relative silence. Fans start up again when temperatures are over 60°C, establishing a speed curve that balances performance and acoustics for work or play.Dual Ball Fan BearingsDifferent bearing types have unique pros and cons. Dual-ball bearings excel at durability and can last up to twice as long as sleeve bearing designs.Vented BackplateLarge backplate vents significantly enhance heat dissipation, helping to keep the GPU cooler during intense tasks. This additional airflow helps ensure optimal temperatures, boosting performance, longevity and stability by defending against overheating and thermal throttling.MaxContact DesignMaxContact is a special ASUS manufacturing process that effectively expands the surface area of the heat spreader that sits atop the GPU by 5%, compared to traditional designs. This improves temperatures by up to 2°C, in concert with an extensive heatsink array and powerful Axial-tech fans.Phase-Change GPU Thermal PadBy melting to effectively fill the gaps between the GPU and the thermal module, a premium phase-change GPU thermal pad provides superior thermal conductivity and enhanced heat dissipation, ensuring optimal performance and longevity for graphics cards under heavy loads.Unmatched ReliabilityASUS GPU Guard & BracketASUS GPU Guard applies adhesive to secure all four corners to reduce the risk of cracks, while a GPU bracket helps ensure uniform mounting pressure and extra stability.Protective BackplateThe PCB is reinforced by a backplate that adds structural rigidity, helping to prevent flex and to protect components and trace pathways from damage.Stainless Steel BracketThe mounting bracket features grade 304 stainless steel, chosen for its strength and high resistance to corrosion.EngineeringDual BIOSDo you prioritize low core temps or low noise levels? Performance mode lets the fans spin up to keep the card running cool all the time, and Quiet mode keeps the same power target and top-end settings while offering a less aggressive fan curve for quieter operation at moderate temperatures.Auto−Extreme TechnologyAn automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass, ASUS Auto-Extreme technology reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption and a more reliable product overall.
LongProductName - 16 GB, GDDR6, 256-bit, PCI Express 5.0, 3x DisplayPort, 1x HDMI, 2x 8-pin, 2.5 slot
LongSummaryDescription - ASUS Prime -RX9070-O16G. Graphics processor family: AMD, Graphics processor: Radeon RX 9070. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR6, Memory bus: 256 bit. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 5.0. Cooling type: Active, Number of fans: 3 fan(s)
Max resolution - 7680x4320
Memory - Data transfer rate - 20 Gbit/s
Memory - Discrete graphics card memory - 16 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bus - 256 bit
Memory bus - 256 bit
Memory CLK - 20 Gbps
Model - PRIME-RX9070-O16G
Packaging content - User guide - Yes
Packaging data - Package depth - 233 mm
Packaging data - Package height - 88.5 mm
Packaging data - Package type - Box
Packaging data - Package weight - 1.75 kg
Packaging data - Package width - 405 mm
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - HDCP - Yes
Performance - HDCP version - 2.3
Performance - OpenGL version - 4.6
Performance - Overclocked (OC) edition - Yes
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - DisplayPort version - 2.1a
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1b
Ports & interfaces - Interface type - PCI Express 5.0
Power - Minimum system power supply - 650 W
Power - Supplementary power connectors - 2x 8-pin
Power connectors - 8+8 pin
Processor - CUDA - No
Processor - Graphics processor - Radeon RX 9070
Processor - Graphics processor family - AMD
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Stream processors - 3584
producerCode - 90YV0LI1-M0NA00
productName - Karta graf. ASUS PRIME RX9070 O16G
ProductName - PRIME-RX9070-O16G
productSize - Normal
Shipping Box Depth Shipping/Package Box Dimensions - 46.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 43.5 cm
Shipping box quantity - 5
Shipping Box Weight Shipping/Package Box Dimensions - 9.65 kg
Shipping Box Width Shipping/Package Box Dimensions - 25.5 cm
ShortSummaryDescription - ASUS Prime -RX9070-O16G, Radeon RX 9070, 16 GB, GDDR6, 256 bit, 7680 x 4320 pixels, PCI Express 5.0
sizeX - 405
sizeY - 235
sizeZ - 90
Stream processors - 3584
Title - ASUS Prime -RX9070-O16G AMD Radeon RX 9070 16 GB GDDR6
Unit Box Height - 0.09
Unit Box Length - 0.41
Unit Box Width - 0.235
Unit Brutto Volume - 0.01032 cubm
Unit Gross Weight - 1.93 kg
Unit Net Weight - 0.7 kg
URL - https://www.asus.com/motherboards-components/graphics-cards/prime/prime-rx9070-o16g/
Vendor Homepage - www.asus.com/motherboards-components/graphics-cards/prime/prime-rx9070-o16g/
WarrantyInfo -
warrantyLength - 36
warrantyType - G
weight - 1760
Weight & dimensions - Depth - 50 mm
Weight & dimensions - Height - 130 mm
Weight & dimensions - Length - 312 mm
Weight & dimensions - Weight - 1.16 kg
