Accessories included - A quick guide Bracket to prevent sagging Anti-sag bracket installation instructions One 16-pin to triple 8-pin power supply
Brand - GIGABYTE
BrandPartCode - GV-N408SWF3V2-16GD
Category - Graphics Cards
category - PC Components|Graphics Cards|NVIDIA
Chipset - GeForce RTX 4080 SUPER
Chipset manufacturer - NVIDIA
code - GV-N408SWF3V2-16GD
Cooling - Active
Core frequency - 2550 MHz
CUDA Core - 10240
Description - Supported NVIDIA DLSS 3, ultra-efficient Ada Lovelace arc and full ray tracing Fourth-generation Tensor cores: up to 4X faster performance with DLSS 3 rendering compared to brute-force rendering Third-generation RT cores: up to 2X ray tracing performance Powered by GeForce RTX 4080 SUPER Integrated with 16 GB GDDR6X 256-bit memory interface WINDFORCE cooling system Dual BIOS Protective metal backplate Anti-sag bracket
Design - Cooling technology - GIGABYTE WINDFORCE 3X
Design - Cooling type - Active
Design - Form factor - Full-Height/Full-Length (FH/FL)
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 405 mm
dimension height - 240 mm
Dimensions - 330 x 136 x 58 mm
dimension weight - 1700 g
dimension width - 95 mm
ean - 4719331354220
EAN - 4719331354220
Graphics card connector - PCI-E 16x ver. 4.0
Gross Weight Kg - 2,11
GTIN - 0889523041697
GTIN - 889523041697
GTIN - 4719331354220
guarantee - 36
guarantee_type - normal
LongDesc - WINDFORCECOOLING SYSTEMThe WINDFORCE cooling system features three 100mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a large copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.ALTERNATE SPINNINGReduce the turbulence of adjacent fans and increase airflow pressure.SMOOTH AIRFLOWGIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.UNIQUE BLADE FANThe airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.GRAPHENE NANO LUBRICANTGraphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.SCREEN COOLINGExtended heatsink design allows air flow to pass through, providing better heat dissipation.LARGE COPPER PLATE & HEAT-PIPEThe large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.DUAL BIOSThe factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.PROTECTION METAL BACK PLATEThe metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.ANTI-SAG BRACKETThe new anti-sag bracket is tailored to each graphics card. It provides the optimized reinforcement and better overall visual appearance.ULTRA DURABLEUltra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.FRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.Power Through The GameGIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.GIGABYTE CONTROL CENTERGIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
LongProductName - NVIDIA GeForce RTX 4080 SUPER, 16GB GDDR6X, 256 bit, 23000MHz, PCI Express 4.0, 1 x HDMI (2.1a), 3 x DP (1.4a), CUDA, DirectX 12 Ultimate, OpenGL 4.6
LongSummaryDescription - GIGABYTE GeForce RTX 4080 SUPER WINDFORCE V2 16G. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 4080 SUPER, Processor frequency: 2550 MHz. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR6X, Memory bus: 256 bit, Memory clock speed: 23000 MHz. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 3 fan(s)
Manufacturer Code - GV-N408SWF3V2-16GD
Manufacturer Name - Gigabyte
Memory - Discrete graphics card memory - 16 GB
Memory - Graphics card memory type - GDDR6X
Memory - Memory bandwidth (max) - 23 GB/s
Memory - Memory bus - 256 bit
Memory - Memory clock speed - 23000 MHz
Memory bus - 256-bit
Memory frequency - 23 Gbps
Memory type - DDR6X
Model - GV-N408SWF3V2-16GD
name - GIGABYTE GeForce RTX 4080 Super Windforce V2, 16384 MB GDDR6X
name - RTX 4080 SUPER WINDFORC E V2 16GB GDDR6X 256bit
Other features - Maximum digital resolution 7680x4320 ATX PCB form Recommended 750W power supply Power connectors 16 pins*1
Other information -
Packaging data - Package depth - 398 mm
Packaging data - Package height - 85 mm
Packaging data - Package type - Box
Packaging data - Package weight - 2.11 kg
Packaging data - Package width - 230 mm
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1a
Ports & interfaces - Interface type - PCI Express 4.0
Power - Minimum system power supply - 750 W
Power - Supplementary power connectors - 1x 16-pin
Processor - CUDA - Yes
Processor - Graphics processor - GeForce RTX 4080 SUPER
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor frequency - 2550 MHz
producer - Gigabyte
ProductName - GeForce RTX 4080 SUPER WINDFORCE V2 16G
Short description - GIGA VGA 16GB RTX4080 SUPER WINDFORCE V2 3xDP/HDMI GeForce RTX 4080 SUPER WINDFORCE V2
ShortSummaryDescription - GIGABYTE GeForce RTX 4080 SUPER WINDFORCE V2 16G, GeForce RTX 4080 SUPER, 16 GB, GDDR6X, 256 bit, 7680 x 4320 pixels, PCI Express 4.0
Supported standards - DirectX 12 Ultimate
Supported standards - OpenGL 4.6
Title - GIGABYTE GeForce RTX 4080 SUPER WINDFORCE V2 16G NVIDIA 16 GB GDDR6X
URL - https://www.gigabyte.com/Graphics-Card/GV-N408SWF3V2-16GD#kf
vendpn - GV-N408SWF3V2-16GD
Version - Box
Video ports - 1 x HDMI
Video ports - 3 x DisplayPort
VRAM memory size - 16 GB
WarrantyInfo - 3 Years
Weight & dimensions - Depth - 136 mm
Weight & dimensions - Height - 58 mm
Weight & dimensions - Length - 330 mm
Weight & dimensions - Weight - 1.36 kg
