Brand - ASUS
BrandPartCode - 90YV0IV1-M0NA00
Card's length - > 280 mm
Category - Graphics Cards
category - PC Components|Graphics Cards|AMD|Radeon RX 7900 XT
Category 1 - Grafikkarten
Category 2 - AMD PCI-Express Grafikkarten
Category Code - VGP
Category_1 - Graphics Cards
Category_2 - Graphics Cards PCIe - AMD
Chipset - AMD Radeon RX 7900 XT
code - 90YV0IV1-M0NA00
Description - ASUS TUF Gaming Radeon™ RX 7900 XT OC Edition 20GB GDDR6 optimized inside and out for lower temps and durability Axial-tech fans scaled up to deliver 14% more airflow Dual ball fan bearings last up to twice as long as conventional designs Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable Metal Exoskeleton adds structural rigidity and vents to increase heat dissipation Auto-Extreme precision automated manufacturing for higher reliability GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring
Design - Cooling technology - ASUS Axial-tech
Design - Cooling type - Active
Design - Illumination - Yes
Design - Illumination colour - Blue, Green, Red
Design - Number of fans - 3 fan(s)
Design - Number of slots - 3.63
Design - Product colour - Grey
Dimensions - 352.9 x 158.2 x 72.6 mm
DisplayPort Input/Output connectors - 3
ean - 4711387020043
EAN - 4711387020043
EAN_code - 4711387020043
Full Description Line - AMD Radeon RX 7900 XT|Graphics memory size 20 GB|GDDR6|320 bit|PCIE 4.0 16x|Memory CLK 20 Gbps|GPU boost clock 2500 MHz|7680x4320|1xHDMI|3xDisplayPort|Included Accessories 1 x TUF certificate of Reliability;1 x TUF Gaming Graphics Card Holder;1 x TUF Velcro Hook & Loop;1 x Collection card;1 x Thank you card;1 x Speedsetup Manual
GPU boost clock - 2500 MHz
Graphic card features - Gaming/HDCP
Graphics connector - PCIE 4.0 16x
Graphics memory size - 20 GB
Graphics memory type - GDDR6
GTIN - 4711387020043
HDMI Input/Output connectors - 1
Included Accessories - 1 x TUF certificate of Reliability;
1 x TUF Gaming Graphics Card Holder;
1 x TUF Velcro Hook & Loop;
1 x Collection card;
1 x Thank you card;
1 x Speedsetup Manual
LongDesc - FLYIN’ TUFThe AMD RDNA™ 3 Architecture elevated by buffed cooling and power delivery to effortlessly churn out frames at 4K resolution and beyond,and backed with an arsenal of rugged reinforcements to cover your six.Lock, load, and dominate with the TUF Gaming Radeon™ RX 7900 XT.AXIAL-TECH UPGRADESAir SuperiorityBigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 14% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.NEW DIRECTIONWell-maintained FormationThe two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 55 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 60 Celsius, referencing a speed curve that balances performance and acoustics for work or play.3.63-SLOT DESIGNPhase That BlazeA generously sized heatsink efficiently soaks up heat from the AMD Radeon™ RX 7900 XT GPU, allowing it to be whisked away by the three Axial-tech fans.MILITARY-GRADE 20K CAPACITORSResilient SquadronA lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.METAL EXOSKELETONSuit UpA diecast frame, aluminum shroud, and backplate prevent PCB flex and feature large vents to further increase heat dissipation.LOCK, LOAD, AND LET THE PERFORMANCE FLOWThe Radeon™ RX 7900 XT gloriously presented on a backdrop of low noise and rugged durability.AUTO-EXTREME TECHNOLOGYRELIABILITY BOOSTAuto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.AURA SYNCLight ‘em Up!Aura-compatible ARGB lighting on the shroud adds a dash of customizable color or functional effects to your build. Pair up with a vast range of compatible system components and coordinate the glow to create a theme that’s uniquely you.GRAPHICS CARD HOLDERPillar of SupportThe bundled graphics card holder banishes sag and also contains a screwdriver to help you build.GPU Tweak IIIASUS GPU Tweak III is more intuitive and feature-rich than ever before. A revamped interface offers greater accessibility by integrating core functions into a centralized dashboard, and our Voltage-Frequency tuner has been overhauled to make overclocking even easier. Additional goodies like 0dB fan technology, automatic profile swapping, a fully customizable on-screen display, and logging capabilities ensure that you get the most out of your graphics card.QuantumCloudQuantumCloud is a safe and easy-to-use application that lets you effortlessly earn extra money by sharing your graphics card’s computing power. Earnings are accessible through your PayPal or WeChat account, and QuantumCloud also supports multiple exchange methods, including Steam. In addition, QuantumCloud doesn’t collect any personal data, so your privacy stays protected. Get started right away with just one click!Pair with a PSUUse our wattage calculator to estimate how much power you’ll need to fuel your rig and then pick a compatible ROG Thor, ROG Loki, or ROG Strix AURA PSU for ultimate performance.
LongProductName - ASUS TUF Gaming Radeon™ RX 7900 XT OC Edition 20GB GDDR6 optimized inside and out for lower temps and durability
LongSummaryDescription - ASUS TUF Gaming TUF-RX7900XT-O20G-GAMING. Graphics processor family: AMD, Graphics processor: Radeon RX 7900 XT. Discrete graphics card memory: 20 GB, Graphics card memory type: GDDR6, Memory bus: 320 bit. Maximum resolution: 7680 x 4320 pixels. OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 3 fan(s), Illumination colour: Blue, Green, Red
Manufacturer - Asus
Manufacturer - ASUS
Manufacturer_code - 90YV0IV1-M0NA00
Max resolution - 7680x4320
Memory - Data transfer rate - 20 Gbit/s
Memory - Discrete graphics card memory - 20 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bus - 320 bit
Memory bus - 320 bit
Memory CLK - 20 Gbps
Model - TUF-RX7900XT-O20G-GAMING
MPN - 90YV0IV1-M0NA00
Name - ASUS Radeon RX 7900 XT TUF GAMING OC, graphics card (RDNA 3, GDDR6, 3x DisplayPort, 1x HDMI 2.1)
name - ASUS Radeon RX 7900 XT TUF O20G, 20480 MB GDDR6
Name - RX 7900XT 20GB ASUS TUF Gaming OC GDDR6 3Fan
Packaging data - Package depth - 226 mm
Packaging data - Package height - 126 mm
Packaging data - Package type - Box
Packaging data - Package weight - 3.16 kg
Packaging data - Package width - 420 mm
Performance - Dual Link DVI - No
Performance - HDCP - Yes
Performance - HDCP version - 2.3
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Interface type - PCI Express 4.0
Power - Minimum system power supply - 750 W
Power - Supplementary power connectors - 3x 8-pin
Power connectors - 8+8+8 pin
Processor - Graphics processor - Radeon RX 7900 XT
Processor - Graphics processor family - AMD
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Stream processors - 5376
ProductName - TUF-RX7900XT-O20G-GAMING
Shipping Box Depth Shipping/Package Box Dimensions - 42 cm
Shipping Box Height Shipping/Package Box Dimensions - 23 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 3.268 kg
Shipping Box Width Shipping/Package Box Dimensions - 13 cm
ShortSummaryDescription - ASUS TUF Gaming TUF-RX7900XT-O20G-GAMING, Radeon RX 7900 XT, 20 GB, GDDR6, 320 bit, 7680 x 4320 pixels, PCI Express 4.0
Stream processors - 5376
Title - ASUS TUF Gaming TUF-RX7900XT-O20G-GAMING AMD Radeon RX 7900 XT 20 GB GDDR6
Unit Brutto Volume - 0.01256 cubm
Unit Gross Weight - 3.27 kg
Unit Net Weight - 1.7 kg
URL - https://www.asus.com/motherboards-components/graphics-cards/tuf-gaming/tuf-rx7900xt-o20g-gaming/
Vendor Homepage - www.asus.com/motherboards-components/graphics-cards/tuf-gaming/tuf-rx7900xt-o20g-gaming/
Warranty - 36 months
WarrantyInfo -
Weight - 3,30
Weight - 3.32
Weight & dimensions - Depth - 76.2 mm
Weight & dimensions - Height - 158.2 mm
Weight & dimensions - Length - 352.9 mm
Weight & dimensions - Weight - 2.16 kg
