APC Smart-UPS SRT1000RMXLI-NC 1000VA, 1000W, IEC, 2U

Accessories included - Software CD Communication cable Power cord suitable for your country Documentation on a CD User's manual Network Management Card Clamps for mounting in industrial cabinets Equipment for mounting devices in the cabinet Mounting brackets for industrial cabinets Temperature sensor USB cable Warranty Card
Active power - 1000 W
Alarm - Audible and visible alarms prioritized by severity
Apparent power - 1000 VA
ARTIKEL1 - SMART-UPS SRT 1000VA RM 230V
ARTIKEL2 - NETWORK CARD IN
Backup time (100% load) - 8.5 min
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 1 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 48 V
Battery - Hot-swap battery - Yes
BatteryType -

Maintenance-free sealed Lead-Acid battery with suspended electrolyte

leakproof

Brand - APC
BrandPartCode - SRT1000RMXLI-NC
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Certification - CE, EAC
Certificates - Compliance certificates - RoHS
Charging time - 3 h
Chassis type - Rack
Color - Black
ControlPanel - Multi-function LCD status and control console
Depth - 505 mm
Description - APC SMART-UPS SRT 1000VA RM 230V NETWORK CARD
Description - APC Smart-UPS SRT 1000VA RM 230V Network Card Power protection with double conversion online with scalable sustaining time, for high density environments.
Design - Cable length - 1.5 m
Design - Display type - LCD
Design - Form factor - Rackmount
Design - International Protection (IP) code - IP20
Design - LED indicators - Status
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 250 mm
dimension height - 610 mm
Dimensions - 432 x 505 x 85 mm 2U
dimension weight - 46000 g
dimension width - 750 mm
ean - 731304340263
EANCode - 0731304340263
Environment requirements - Operating temperature: 0 - 40 ° C Relative humidity during operation: 0 - 95% (without condensation) Height m.p. during operation: 0-3000 m Temperature (storage): (-20) - 50 ° C Relative humidity (storage): 0 - 95% (without condensation) Height m.p. (storage): 0-15000 m
Features - Audible alarm(s) - Yes
Features - Crest factor - 3:1
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 40/70 Hz
Features - Input operation voltage (max) - 150 V
Features - Input operation voltage (min) - 50 V
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 1000 W
Features - Output power capacity - 1 kVA
Features - Surge energy rating - 432 J
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Voltage drop
FormFactor - Rack
GrossWeight - 29.600 Kg
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304340263
GTIN - 0731304340263
guarantee - 36
guarantee_type - external
Height - 85 mm
Height - 240.000000
HERSTELLER - APC
HSTNUMMER - SRT1000RMXLI-NC
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 2.0
InputConnections -

British BS1363A

IEC-320 C14

Schuko CEE 7/EU1-16P

InputFrequency - 40 - 70 Hz (auto sensing)
Input power ports - IEC-C14
Input power ports - Type F Schuko
Input power ports - Type G British
Input power ports - Wtyczka sieciowa
InputVoltage - 230V
InterfacePorts -

RJ-45 Serial

Smart-Slot

USB

Length - 747.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 12 pc(s)
Logistics data - Total carbon footprint (kg of CO2e) - 1843.14
LongDesc -
LongDesc - Stay always online and prevent data lossAn APC Smart-UPS On-Line always supplies perfectly clean power to all connected equipment thanks to its double conversion technology. Even power failures have no effect on this. The APC Smart-UPS On-Line then automatically supplies emergency power without having to switch. This prevents unwanted failure of, for example, a PC, server, storage or switch. With the APC PowerChute Network Shutdown software, you can even have critical IT hardware shut down automatically and in a controlled manner if the UPS battery is almost empty. This prevents data loss, downtime and physical damage to hardware.Extend the runtimeYou can easily increase the number of minutes that the APC SRT1000RMXLI-NC can supply emergency power independently by connecting external battery packs (SRT48RMBP). A runtime of several hours is even possible.AvailabilityThe Smart-UPS On-Line has an internal bypass and uses double conversion, which maximizes the availability and lifespan of connected hardware. It also makes the UPS compatible with an emergency generator. The On-Line double conversion technology ensures clean, uninterrupted power to protected equipment, even when generator power is used.SafetyIn addition, a Smart-UPS On-Line protects connected devices against peak voltages caused by lightning, among other things. This APC emergency power supply is ideally suited for business use.Ease of useThe APC Smart-UPS SRT is easy to operate thanks to a tiltable graphic LCD screen and physical buttons. This makes it possible to set and read out the basic functionalities. Because the background color of the screen changes depending on the type of warning, the seriousness of the situation can be quickly visually assessed. Thanks to the included 4-post rail kit, you can easily mount the UPS in a rack (2U).Manage your Smart-UPSThanks to the pre-installed APC Network Management Card (AP9641), you can easily connect the APC UPS to the network. This allows you to monitor and manage the UPS remotely (SNMP) and the UPS can send a shutdown signal to multiple physical and/or virtual servers using PowerChute Network Shutdown software.PowerChute Network ShutdownPowerChute Network Shutdown is UPS management software that works with the UPS Network Management Card to protect Windows, Linux and Host ESXi, but also hyperconverged and virtual infrastructure*. In the event of a power failure, PowerChute can shut down your virtual machines correctly and the pre-configured boot sequence ensures that they are turned back on.*For HCI and virtual machine support an additional license is required:1 year: SWPCNS1Y-DIGI3 years: SWPCNS3Y-DIGI5 years: SWPCNS5Y-DIGIRemote management and monitoring of your networkThe network card can be managed remotely via the user-friendly web browser interface, remote management software EcoStruxure™ IT (SFTWES1-DIGI) or another SNMP-compatible system. Tip EcoStruxure™ IT also includes the functionalities of the support contract below.Support contractThe optional network card support contract license* ensures that you are always up-to-date and secure and includes additional benefits such as frequent updates with:• New and improved functions• Security updates• Advanced support(The functionality of the support contract is included free of charge in the first year of the UPS)*The above license and available in the variants:1 year: SWNMC3SU-1Y-DIGIUp to (Replace the bold number in the article number with the desired variant)6 years: SWNMC3SU-6Y-DIGIExtend the lifespanThe internal battery cartridge (APCRBC155) can be replaced easily, safely and independently by the user. This without having to switch off the APC SRT1000RMXLI-NC or connected equipment. This way you can easily and cheaply extend the lifespan of the APC Smart-UPS and your equipment will always remain online.Warranty extensionThe factory warranty of the SRT1000RMXLI-NC is 3 years, with the exception of the battery cartridge, which has a factory warranty of 2 years. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-02).Switched Outlet Groups: Remote reboot and phased start-upThanks to the Switched Outlet Groups it is possible to configure a phased/delayed power-on per UPS outlet group. This reduces the peak load on the UPS and brings it closer to the constant load, which can limit oversizing of the UPS.It is also possible to reset a group of multiple UPS outlets and the equipment connected to them. If a network card (ap9640) is used in combination with Ecostruxure IT Expert (SFTWES1-DIGI), this can even be done remotely stand.You can also disable non-critical loads; this extends the runtime for critical equipment.This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 1000VA on-line 2U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with IEC 320 C14, BS1363A British and Schuko CEE 7/EU1-16P inputs, and 6x IEC 320 C13 outlets. The UPS has a preinstalled Network Management Card for UPS network-based monitoring and management. It comes with BS1363A British, IEC 60320 C20, and Schuko CEE 7/EU1-16P inputs, 6x IEC 320 C13/60320 C13 outlets. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It conforms to CE and EAC. Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
LongProductName - APC Smart-UPS On-Line SRT1000RMXLI-NC - 1kW/VA, 6x C13 output, rackmount, NMC
LongSummaryDescription - APC Smart-UPS On-Line SRT1000RMXLI-NC - 1kW/VA, 6x C13 output, rackmount, NMC. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 1000 W. Serial interface type: RJ-45. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 48 V, Battery life (max): 5 year(s). Form factor: Rackmount, Product colour: Black, Cable length: 1.5 m. Compliance certificates: RoHS, Certification: CE, EAC
Manufacturer - APC
ManufacturerPartNumber - SRT1000RMXLI-NC
MANUFDATASHEET - https://www.apc.com/shop/ai/en/products/APC-Smart-UPS-SRT-1000VA-RM-230V-Network-Card/P-SRT1000RMXLI-NC
name - SRT1000RMXLI-NC SmartUP SRT1kVA/1kW 230V Rack N
No. of batteries - 1
Number of phases input - 1 (230V)
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features -
OutputConnections - (6) IEC 320 C13 (Battery Backup)
OutputFrequency - 50/60Hz +/- 3 Hz
Output power ports - 6 x IEC-C13
OutputVoltage - 220 V, 240 V
PackageContents -

CD with software

Comms cable

Country-specific detachable power cord

Documentation CD

Installation guide

Network Management Card

Rack Mounting brackets

Rack mounting hardware

Rack Mounting support rails

Temperature Probe

USB cable

Warranty card

Packaging data - Package depth - 749 mm
Packaging data - Package height - 246 mm
Packaging data - Package weight - 29.6 kg
Packaging data - Package width - 594 mm
PeriodofWarranty - 2 Y
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
PowerVAW - 1000 VA
PowerW - 1000 W
ProdDesc - APC Smart-UPS SRT 1000VA RM 230V Network Card
producer - APC
ProductName - APC Smart-UPS On-Line SRT1000RMXLI-NC - 1kW/VA, 6x C13 output, rackmount, NMC
ProductPicture - http://www.tdbaltic.ee/images/ds4/SRT1000RMXLI-NC-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
RechargeTime - 3 h
RJ45 - Yes
Runtime - 21.1/8.4
ShortSummaryDescription - APC Smart-UPS On-Line SRT1000RMXLI-NC - 1kW/VA, 6x C13 output, rackmount, NMC, Double-conversion (Online), 1 kVA, 1000 W, Sine, 50 V, 150 V
SmartSlot - Yes
Software - PowerNet MIB v4.2.8
Special functions -
Stck_Kart - 1
Stck_Pal - 1
Storno - Y
Sustainability - Sustainability certificates - Green Premium
Title - APC Smart-UPS On-Line SRT1000RMXLI-NC - 1kW/VA, 6x C13 output, rackmount, NMC
Topology - Online
UPS Architecture - on-line double conversion
UPS devices and accessories - Yes
URL - https://www.apc.com/
USB - Yes
vendpn - SRT1000RMXLI-NC
Voltage - 230 V
Warranty - 2 years
WarrantyInfo - 3 years
WaveformType - Sine wave
Weight - 21 kg
Weight - 21.000 Kg
Weight - 36.000000
Weight & dimensions - Depth - 505 mm
Weight & dimensions - Height - 85 mm
Weight & dimensions - Weight - 21 kg
Weight & dimensions - Width - 432 mm
Width - 432 mm
Width - 605.000000
