APC Smart-UPS SMT3000IC 3000VA, 2700W, IEC

Accessories included -
Active power - 2700 W
Alarm - Alarm when on battery : distinctive low battery alarm : configurable delays
Apparent power - 3000 VA
ARTIKEL1 - SMART-UPS 3000VA LCD 230V
ARTIKEL2 - WITH SMARTCONNECT IN
Battery - Automatic battery test - Yes
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 3 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - Yes
Battery - Typical backup time at full load - 5.1 min
Battery - Typical backup time at half load - 17.2 min
BatteryType -

Maintenance-free sealed Lead-Acid battery with suspended electrolyte

leakproof

Brand - APC
BrandPartCode - SMT3000IC
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Certificates - Certification - CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH, PEP, EOLI
Certificates - Compliance certificates - RoHS
Chassis type - Tower
Color - Black
ControlPanel - Multi-function LCD status and control console
Depth - 544 mm
Depth, mm - 544
Description - APC SMART-UPS 3000VA LCD 230V WITH SMARTCONNECT
Description - Zasilacz awaryjny SMT3000IC SmartUPS 3kVA / 2.7kW Tower SmartConnect
Design - Cable length - 1.83 m
Design - Display type - LCD
Design - Form factor - Tower
Design - LED indicators - Status
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 670 mm
dimension height - 370 mm
Dimensions -
dimension weight - 59500 g
dimension width - 760 mm
ean - 731304337331
EAN - 0731304337331
EANCode - 0731304337331
Eans - 0731304337331
Environment requirements -
Features - Audible alarm(s) - Yes
Features - Auto-restart - Yes
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Efficiency - 98.4%
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 302 V
Features - Input operation voltage (min) - 151 V
Features - Noise level - 53 dB
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 2700 W
Features - Output power capacity - 3 kVA
Features - Surge energy rating - 365 J
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
FormFactor - Tower
Form factor - Tower
GrossWeight - 52.500 kg
Gross Weight Kg - 63,7
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304337331
GTIN - 0731304337331
guarantee - 36
guarantee_type - external
Height - 435 mm
Height - 675.000000
Height, mm - 435
HERSTELLER - APC
HSTNUMMER - SMT3000IC
I/O connectors - 1 x USB 2.0
I/O connectors - 2 x RJ-45 LAN
Input connection - IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A
InputConnections -

IEC-320 C20

Schuko CEE 7 / EU1-16P

British BS1363A

InputFrequency - 50/60 Hz +/- 3 Hz (auto sensing)
Input frequency, Hz - 50/60
Input power ports - IEC-C20
InputVoltage - 230V
Interface - USB
InterfacePorts -

SmartSlot

USB

Length - 754.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 9 pc(s)
Logistics data - Total carbon footprint (kg of CO2e) - 3335.07
LongDesc -
LongDesc - Stay always online and prevent data lossAs soon as the power fails, an APC Smart-UPS immediately supplies emergency power to all connected equipment. Because an APC UPS does this automatically, you prevent unwanted failure of, for example, a PC, server or switch. With the free APC PowerChute software, you can even have critical IT hardware shut down automatically and in a controlled manner when the UPS battery is almost empty. This prevents data loss, downtime and physical damage to hardware.SafetyIn addition, a Smart-UPS protects connected devices against peak voltage caused by lightning, among other things. This APC emergency power supply is ideally suited for (small) business use.Battery lifeWith the help of the SmartConnect Ethernet port, you can easily connect the Smart-UPS to your network and you can easily monitor it remotely. This can be done via the secure and freely accessible APC SmartConnect cloud-based web portal or via EcoStruxure It Expert.SmartConnectOut-of-box remote UPS monitoring, free during a 6-month trial period. Using the SmartConnect Ethernet port, you can easily connect the Smart-UPS to your network and monitor it remotely via the secure APC SmartConnect cloud-based web portal*. In addition, the UPS can always be monitored via this port via EcoStruxure IT Expert (SFTWES1-DIGI).* Extend access to SmartConnect via the following licenses:1 year Standard Plan: ERWPMON1-1Y-DIGI3 years Standard Plan: ERWPMON1-3Y-DIGI1 year Advanced Plan: ERWPLUS1-1Y-DIGI3 years Advanced Plan: ERWPLUS1-3Y-DIGIPowerChuteBy connecting the UPS to a maximum of one server via a USB cable, it can automatically provide it with a shutdown signal during a prolonged power failure and thus still prevent a hard shutdown. This exact moment can be set via the free APC PowerChute Serial Edition software.Network Management CardIf you connect the UPS directly to your network via the optional APC Network Management Card (AP9640/AP9641), it can be easily managed remotely via SNMP or our remote management software Ecostruxure IT Expert (SFTWES1-DIGI). You can also automatically send a shutdown signal via the network to multiple physical and/or virtual servers. By means of the APC PowerChute Network Shutdown Software belonging to the network card, it is even possible to differentiate between the shutdown moment and the order in which this happens.Ease of useBy means of physical buttons and an LCD screen, it is possible to set and read out the basic functionalities.Extend the lifespanThe internal battery cartridge (RBC55) can be easily, safely and independently replaced by the user. This without having to switch off the APC SMT3000IC or connected equipment. This way you can easily and cheaply extend the life of the APC Smart-UPS and your equipment always stays online.Warranty extensionThe factory warranty of the SMT3000IC is 3 years, with the exception of the battery cartridge, which has a factory warranty of 2 years. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-04).Switched Outlet Groups: Remote reboot and phased start-upThanks to the Switched Outlet Groups it is possible to configure a phased/delayed power-on per UPS outlet group. This reduces the peak load on the UPS and brings it closer to the constant load, which can limit oversizing of the UPS.It is also possible to reset a group of multiple UPS outlets and the equipment connected to them. If SmartConnect Advanced (ERWPLUS1-1Y-DIGI), a UPS with SmartConnect port + Ecostruxure IT Expert (SFTWES1-DIGI) or a network card (ap9640) in combination with Ecostruxure IT Expert (SFTWES1-DIGI) are used, this can even be done remotely.This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 3kVA line interactive tower UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with IEC 320 C20 input, BS1363A British and Schuko CEE 7/EU1-16P input cables, 8x IEC 320 C13 and 1x IEC 320 C19 outlets, and 2x IEC jumper cables. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 2-year warranty and comes with a built-in lead-acid battery. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
LongProductName - APC Smart-UPS SMT3000IC - 8x C13, 1x C19, USB, SmartConnect, 3000VA
LongSummaryDescription - APC Smart-UPS SMT3000IC - 8x C13, 1x C19, USB, SmartConnect, 3000VA. UPS topology: Line-Interactive, Output power capacity: 3 kVA, Output power: 2700 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 9 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 5.1 min, Typical backup time at half load: 17.2 min. Form factor: Tower, Product colour: Black, Cable length: 1.83 m. Compliance certificates: RoHS, Certification: CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH, PEP, EOLI
Manufacturer - APC
Manufacturer Code - SMT3000IC
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - SMT3000IC
MANUFDATASHEET - https://www.apc.com/shop/mn/en/products/APC-Smart-UPS-3000VA-LCD-230V-with-SmartConnect/P-SMT3000IC
MPN - SMT3000IC
Name - APC Smart-UPS Tower SMT3000IC 2700W 3000VA Line Interactive
Name - APC Smart SMT3000IC
name - SMT3000IC SmartUPS 3kVA 2.7kW Tower SmartConnect
Noise level, dB - 53
Nominal input voltage, V - 230
Nominal output voltage, V - 230
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0-95
Operating temperature range (T-T), °C - 0-40
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features -
OutputConnections -

(1) IEC 320 C19 (Battery Backup)

(2) IEC Jumpers (Battery Backup)

(8) IEC 320 C13 (Battery Backup)

OutputFrequency - 50/60Hz +/- 3 Hz
Output power, W - 2700
Output power capacity (VA) - 3000
Output power ports - 1 x IEC-C19
Output power ports - 8 x IEC-C13
OutputVoltage - 230 V
PackageContents -

CD with software

Documentation CD

USB cable

Packaging content - Cables included - RS-232, USB cable
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 762 mm
Packaging data - Package height - 699 mm
Packaging data - Package weight - 63.7 kg
Packaging data - Package width - 381 mm
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 9 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Ports & interfaces - Number of output IEC jumpers - 2
Ports & interfaces - Power plug - C20 coupler
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB port - Yes
PowerVAW - 3000 VA
PowerW - 2700 W
ProdDesc - APC Smart-UPS 3000VA LCD 230V with SmartConnect
producer - APC
Producer - APC
ProducerCode - SMT3000IC
ProductName - APC Smart-UPS SMT3000IC - 8x C13, 1x C19, USB, SmartConnect, 3000VA
ProductPicture - http://www.tdbaltic.ee/images/ds4/SMT3000IC-01.jpg
ProductPicture2 - http://www.tdbaltic.ee/images/ds4/SMT3000IC-02.jpg
ProductPicture3 -
ProductPicture4 -
RechargeTime - 3 h
RJ45 - -
Runtime - -
ShortDescription -
Short description - APC Smart-UPS 3000 VA LCD mit SmartConnect
ShortSummaryDescription - APC Smart-UPS SMT3000IC - 8x C13, 1x C19, USB, SmartConnect, 3000VA, Line-Interactive, 3 kVA, 2700 W, Sine, 151 V, 302 V
SmartSlot - Yes
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 1
Storage temperature range (T-T), °C - -15-45
Storno - Y
Sustainability - Sustainability certificates - Green Premium
Title - APC Smart-UPS SMT3000IC - 8x C13, 1x C19, USB, SmartConnect, 3000VA
Topology - Line interactive
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL - https://www.apc.com/
USB - Yes
vendpn - SMT3000IC
Warranty - 2 years
WarrantyInfo - 3 years
WaveformType - Sine wave
Weight - 52.500 Kg
Weight - 60
Weight - 60.000000
Weight & dimensions - Depth - 544 mm
Weight & dimensions - Height - 435 mm
Weight & dimensions - Weight - 52.5 kg
Weight & dimensions - Width - 197 mm
Weight, kg - 52.5
Width - 197 mm
Width - 368.000000
Width, mm - 197
