APC Smart-UPS SRT2200RMXLI 2200VA, 1980W, IEC, 2U

Accessories included - - 1 x kabel zasilający - 2,44 m,
- 1 x kabel szeregowy - zewnętrzna,
- 1 x kabel USB - zewnętrzne,
- Zestaw do montażu w stojaku.
Active power - 1980 W
Alarm - Audible and visible alarms prioritized by severity
Apparent power - 2200 VA
ARTIKEL1 - SMART UPS SRT
ARTIKEL2 - 2200VA RM 230V IN
Backup time (100% load) - 3.9 min
Battery - Automatic battery test - Yes
Battery - Battery capacity - 367 VAh
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 3 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - Yes
Battery - Number of batteries supported - 1
Battery - Typical backup time at full load - 3.9 min
Battery - Typical backup time at half load - 11.6 min
Battery capacity - 0 mAh
Battery recharge time, h - 3
Battery technology - Lead-Acid
BatteryType -

Maintenance-free sealed Lead-Acid battery with suspended electrolyte

leakproof

Brand - APC
BrandPartCode - SRT2200RMXLI
Cable length, m - 2.44
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Certificates - Certification - CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH
Certificates - Compliance certificates - RoHS
Certification - CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, ENERGY STAR (EU), RCM, VDE
Charging time - 3 h
Chassis type - Rack
Chassis type - Tower
Color - Black
Connections - RJ-45 Serial
Connections - Smart-Slot
Connections - USB
Connectors - 1 x USB 2.0
Connectors - RJ-45
Connectors - SmartSlot
ControlPanel - Multi-function LCD status and control console
Depth - 584 mm
Depth, mm - 584
Description - APC SMART-UPS SRT 2200VA RM 230V
Description - Rack zamienny system UPS w kolorze czarnym.
Design - Cable length - 2.44 m
Design - Display type - LCD
Design - Form factor - Rackmount/Tower
Design - International Protection (IP) code - IP20
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack capacity - 2U
Designation - CE+WEEE
dimension depth - 85 mm
dimension height - 440 mm
Dimensions - 43.2 cm x 58.4 cm x 8.5 cm (szerokość x głębokość x wysokość)
dimension weight - 34000 g
dimension width - 590 mm
ean - 731304317623
EAN - 0731304317623
EANCode - 0731304317623
Environment requirements - - Minimalna temperatura pracy 0 ° C,
- Maks. Temperatura pracy 40 ° C,
- Wilgotnosc  0 - 95% (bez kondensacji).
Features - Audible alarm(s) - Yes
Features - Auto-restart - Yes
Features - Crest factor - 3:1
Features - Efficiency - 92.2%
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 40/70 Hz
Features - Input operation voltage (max) - 275 V
Features - Input operation voltage (min) - 100 V
Features - Noise level - 55 dB
Features - Output frequency regulation - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 1980 W
Features - Output power capacity - 2.2 kVA
Features - Surge energy rating - 340 J
Features - Surge protection - Yes
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Features - Web-based management - Yes
Form factor - Rack
FormFactor - Tower
Frequency range, Hz - 50/60 +/- 3
Gewicht - 33
GrossWeight - 28.000 kg
Gross Weight Kg - 34,02
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304317623
GTIN - 0731304317623
guarantee - 36
guarantee_type - external
Height - 432 mm
Height - 610.000000
Height, mm - 85
HERSTELLER - APC
Hold-up time (maks) - 0 s
HSTNUMMER - SRT2200RMXLI
Input connection - IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A
InputConnections - IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A
InputFrequency - 40 - 70 Hz (auto sensing)
Input frequency, Hz - 40 - 70
Input power ports - IEC-C20
InputVoltage - 230 V
InterfacePorts - RJ-45 Serial , Smart-Slot , USB
Length - 250.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 12 pc(s)
Logistics data - Total carbon footprint (kg of CO2e) - 3656.4
LongDesc -
LongDesc - Stay always online and prevent data lossAn APC Smart-UPS On-Line always supplies perfectly clean power to all connected equipment thanks to its double conversion technology. Even power failures have no effect on this. The APC Smart-UPS On-Line then automatically supplies emergency power without having to switch. This prevents unwanted failure of, for example, a PC, server, storage or switch. With the free APC PowerChute software, you can even have critical IT hardware shut down automatically and in a controlled manner when the UPS battery is almost empty. This prevents data loss, downtime and physical damage to hardware.Extend the runtimeYou can easily increase the number of minutes that the APC SRT2200RMXLI can supply emergency power independently by connecting external battery packs (SRT72RMBP). A runtime of several hours is even possible.AvailabilityThe Smart-UPS On-Line has an internal bypass and uses double conversion, which maximizes the availability and lifespan of connected hardware. It also makes the UPS compatible with an emergency generator. The On-Line double conversion technology ensures clean, uninterrupted power to protected equipment, even when generator power is used.SafetyIn addition, a Smart-UPS On-Line protects connected devices against peak voltages caused by lightning, among other things. This APC emergency power supply is ideally suited for business use.Ease of useThe APC Smart-UPS SRT is easy to operate thanks to a tiltable graphic LCD screen and physical buttons. This makes it possible to set and read out the basic functionalities. Because the background color of the screen changes depending on the type of warning, the seriousness of the situation can be quickly visually assessed. Thanks to the included 4-post rail kit, you can easily mount the UPS in a rack.Network Management CardIf you connect the UPS directly to your network via the optional APC Network Management Card (AP9640/AP9641), it can be easily managed remotely via SNMP or our remote management software Ecostruxure IT Expert (SFTWES1-DIGI). You can also automatically send a shutdown signal via the network to multiple physical and/or virtual servers. By means of the APC PowerChute Network Shutdown Software belonging to the network card, it is even possible to differentiate the shutdown moment and the order in which this happens.Extend the lifespanThe internal battery cartridge (APCRBC141) can be easily, safely and independently replaced by the user. This without having to switch off the APC SRT2200RMXLI or connected equipment. This way you can easily and cheaply extend the lifespan of the APC Smart-UPS and your equipment always remains online.Warranty extensionThe factory warranty of the SRT2200RMXLI is 3 years, with the exception of the battery cartridge, which has a factory warranty of 2 years. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-04).Switched Outlet Groups: Remote reboot and phased start-upThanks to the Switched Outlet Groups, it is possible to configure a phased/delayed power-on per UPS outlet group. This reduces the peak load on the UPS and brings it closer to the constant load, which can limit oversizing of the UPS.It is also possible to reset a group of multiple UPS outlets and the equipment connected to them. If a network card (ap9640) is used in combination with Ecostruxure IT Expert (SFTWES1-DIGI), this can even be done remotely.You can also switch off non-critical loads; this extends the runtime for critical equipment.Included in the box1x SRT2200RMXLI1x USB cable1x C13 to C14 powercord 1.2M1x Software CD with Powershute Business Edition1x Documentation CD1x Schuko to C19 input powercord 2M1x British BS1363A to C19 input powercord1x C19 to C20 input powercord 2.5M2x Rackmount bracketsThis APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 2200VA on-line 2U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with BS1363A British, IEC 320 C20, and Schuko CEE 7/EU1-16P inputs, 8x IEC 320 C13 and 2x IEC 320 C19 outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. It comes with BS1363A British, IEC 60320 C20, and Schuko CEE 7/EU1-16P inputs, 8x IEC 320 C13/60320 C13 and 2x IEC 320 C19/60320 C19 outlets. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It conforms to CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, and VDE. Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
LongProductName - APC Smart-UPS On-Line SRT2200RMXLI - 2200VA, 8x C13 & 2x C19, rack mount
LongSummaryDescription - APC Smart-UPS On-Line SRT2200RMXLI - 2200VA, 8x C13 & 2x C19, rack mount. UPS topology: Double-conversion (Online), Output power capacity: 2.2 kVA, Output power: 1980 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 367 VAh, Typical backup time at full load: 3.9 min. Form factor: Rackmount/Tower, Product colour: Black, Rack capacity: 2U. Compliance certificates: RoHS, Certification: CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH
Manufacturer - APC
Manufacturer Code - SRT2200RMXLI
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - SRT2200RMXLI
MANUFDATASHEET - http://www.apc.com/shop/ee/en/products/APC-Smart-UPS-SRT-2200VA-230V/P-SRT2200XLI
Maximum output power capacity (VA) - 2200
Maximum power, W - 1980
MPN - SRT2200RMXLI
Name - APC Smart-UPS SRT2200RMXLI 1980W 2200VA 2HE
name - SRT2200RMXLI Smart-UPS S RT2200VA/1980W 230V Rac
No. of batteries - 1
Nominal input voltage, V - 230 (220, 240)
Nominal output voltage, V - 230 (220, 240)
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0 - 95
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features -
Other features - Nominal input voltage - 230 V
Other features - Nominal output voltage - 230 V
OutputConnections -

(2) IEC 320 C19 (Battery Backup)

(8) IEC 320 C13 (Battery Backup)

OutputFrequency - 50/60Hz +/- 3 Hz
Output interface - 2 x IEC 320 C19, 8 x IEC 320 C13
Output power, W - 1980
Output power capacity (VA) - 2200
Output power ports - 2 x IEC-C19
Output power ports - 8 x IEC-C13
OutputVoltage - 240 V
PackageContents -

CD with software

Country-specific detachable power cord

Documentation CD

Installation guide

Removable support feet

USB cable

Warranty card

Packaging content - Cables included - USB cable
Packaging content - Quick installation guide - Yes
Packaging content - Rack mount kit - Yes
Packaging data - Bracket - Yes
Packaging data - Package depth - 810 mm
Packaging data - Package height - 246 mm
Packaging data - Package weight - 34 kg
Packaging data - Package width - 599 mm
Packaging data - Software CD - Yes
PeriodofWarranty - 3 Y
Ports & interfaces - AC outlets quantity - 10 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Ports & interfaces - Number of output IEC jumpers - 2
Ports & interfaces - Power plug - C20 coupler
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB port - Yes
PowerVAW - 2200 VA
PowerW - 1980 W
ProdDesc - Smart-UPS SRT 2200VA/1980W 230V RM online, 3.9 min@full load
producer - APC
ProductName - APC Smart-UPS On-Line SRT2200RMXLI - 2200VA, 8x C13 & 2x C19, rack mount
ProductPicture - http://www.tdbaltic.ee/images/ds4/SRT2200XLI-01.jpg
ProductPicture2 - http://www.tdbaltic.ee/images/ds4/SRT2200XLI-02.jpg
ProductPicture3 - http://www.tdbaltic.ee/images/ds4/SRT2200XLI-03.jpg
ProductPicture4 - http://www.tdbaltic.ee/images/ds4/SRT2200XLI-04.jpg
Rack height (units) - 2
RechargeTime - 3 h
RJ45 - Yes
Runtime - 4 min (full load) / 12 min (half load)
Runtime - 11.6/3.9
Short description - APC Smart-UPS SRT 2200 VA RM SRT2200RMXLI
ShortSummaryDescription - APC Smart-UPS On-Line SRT2200RMXLI - 2200VA, 8x C13 & 2x C19, rack mount, Double-conversion (Online), 2.2 kVA, 1980 W, Sine, 100 V, 275 V
SmartSlot - Yes
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 8
Storage temperature range (T-T), °C - -15 - 45
Storno - Y
Surge energy rating, J - 340
Sustainability - Sustainability certificates - ENERGY STAR, Green Premium
Title - APC Smart-UPS On-Line SRT2200RMXLI - 2200VA, 8x C13 & 2x C19, rack mount
Topology - Online
Transfer time (max) - 0 s
UPS Architecture - on-line double conversion
UPS devices and accessories - Yes
URL - https://www.apc.com/
USB - Yes
vendpn - SRT2200RMXLI
Voltage - 230 V
Warranty - 3 years
WarrantyInfo - 3 years repair or replace (excluding battery) and 2 years for battery
WaveformType - Sine wave
Weight - 25 kg
Weight - 25.000 Kg
Weight - 25.7
Weight - 34.000000
Weight & dimensions - Depth - 584 mm
Weight & dimensions - Height - 85 mm
Weight & dimensions - Weight - 25 kg
Weight & dimensions - Width - 432 mm
Weight, kg - 25
Width - 85 mm
Width - 830.000000
Width, mm - 432
